785nm Laser Portable Raman Spectrometer Analyzer Machine for Chemical Analysis
LATR6500 is the 4th generation handheld Raman analyzer, with compact size, lightweight (450g), and easy-to-held, it can be widely applied to industries of customs, public safety, |ab, plant, warehouse, deck etc. It can fast detect drugs, precursor chemicals, explosives, gemstones, raw materials, and also fast identify additives, residues of pesticide & veterinary drugs.
Excellent spectral identification algorithm are embedded in Handheld Raman spectrometers to easily identify substance, and enable users to add their own spectral data. It employs Android system, simple interface，5.5" high definition screen, double cameras of 13-mega plus 8-mega taking evidence pictures in the field, multiple modes of inbuilt WIFI, Bluetooth, GPS etc.
Laboao company provides full technical support and services, including spectral library building, method & verification, IQ/OQ/PQ validation etc.
Intelligent Mobile Instrument Available in Your Hand!
Feature:
1. Non-Destructive, Fast Detect & ldentify, One-touch Operation
2. Advanced algorithm, mixture detection
3. HD 5.5" capacitive touch screen, smooth operation system
4. double cameras of 13-mega plus 8-mega
5. Barcode & QR scan
6. Precision GPS positioning
7. Multiple modes of 4G, GPS, GPRS, Bluetooth, WIFI
8. Self-Built Spectral Library
9. Test results report export pdf
10. Built-in Li battery continuous operation 4-6hrs
11. Lightweight (450g) ，easy-to-take
12. IP-67
Application:
Public Safety; Food Safety
Dangerous Chemicals Detect at High Speed Train, Metro Entrance
APls & Pharmaceutical Excipients
Gemstones & Materials ldentification, Mineral sorting
Experimental Research
Antique authentication
|
Model |
LATR-6500 |
||
|
Operative System |
Android |
||
|
Excitation Wavelength |
785±0.5nm |
||
|
Wavenumber Range |
200-4000cm-1 |
||
|
Resolution |
10cm-1 |
||
|
Touch Screen |
5.5” , 1920x1080,c |
||
|
Size |
6.7”x3.1”x1.2” |
||
|
Weight |
450g |
||
|
Interface |
WIFI, USB Type-C, Bluetooth, GSM |
||
|
Export Report |
Export report including detect result, spectral info, evident pictures |
||
|
Battery |
4-6hour continuous operation |
||
|
Charging Type |
USB Type-C |
||
|
Operating Temperature |
-20 ~ 50°C |
