Microbial Membrane Filtration System

Name: Microbial Membrane Filtration System
Brand: BEYONDBIO TECH
SKU: BTK-MFS-007
Price: 300.00 USD
Availability: InStock

No.BTK-MFS-007

This microbial membrane filtration system captures microbes and particles on filter membranes for routine microbiological testing. It features independent control for each port and supports PP or stainless steel funnels. Compatible with 47mm/50mm membranes, the 6-place manifold allows fast filtration and can be sterilized by moist heat. It is widely used for microbial limit tests in pharmaceutical, food, water and cosmetic industries.

$300.00

Get the latest quote

SPECIFICATION

Overview

The microbial membrane filtration system is engineered for analysis of particles and microorganisms trapped on the surface of membrane filters. Simple operation makes it suitable for daily laboratory microbiology tests. Stainless steel taps installed on the base control vacuum on and off. Users can select PP funnels or stainless steel funnels according to testing requirements.

Features

Detachable filter head for easy sterilization of core components.
Multi-head manifold with independent control of each filtration position.
Large effective filtration area delivers fast filtration speed.
Compatible with 47mm and 50mm filter membranes.
Filter head supports rapid flame sterilization.
Special membrane removal groove to conveniently take out filter membranes after filtration.
The filtration manifold support can withstand moist heat sterilization.

Technical Parameters

PP Funnel Volume: 270ml
PP Funnel Scale: 50, 100, 150, 200, 250ml with annular scale lines
Compatible Membrane Diameter: 47mm, 50mm
Effective Filtration Area: 12.5 cm²
Dimension W × H: 105mm × 135mm
Funnel Material: PP / Stainless Steel
Manifold Support Material: Stainless Steel
Filter Head: Detachable, screw-mounted to holder, 6-place
Stainless Steel Funnel Models: SS100 (100ml), SS250 (300ml), SS500 (500ml)

Optional Accessories

PP funnel, stainless steel funnel (100ml, 300ml, 500ml), lid for 300ml SS funnel, SS funnel clamp, diaphragm vacuum pump, sterile filter membrane, flame sterilization tool, tweezers, tweezer stand, flask fittings

Application

Disease Control: Microbiological detection of legionella, public water and food samples.
Pharmaceutical Industry: Microbial limit test and chemical analysis of purified water, medicines and raw materials.
Food & Beverage: Bottled water, packaged water, beer, beverages and liquid raw materials in production.
Filtration for chemical, cosmetic and electronic industries.
Quality supervision and inspection.
Waterworks, water supply and sewage testing.
