Portable Ophthalmic Instruments Full Scale Ophthalmic UBM Ultrasound Biomicroscope
This system is widely used in medical and health institutions, laboratories, research institutes, and higher education institutions for bacteriological observation, teaching and research, clinical experiments, and routine medical testing
Product advantages:
1. High definition color digital imaging.
2. Easily achieve digital image acquisition and storage.
3. Provides scientific level lossless image output.
4. It can help users easily complete the acquisition, storage, editing, processing, and various image measurement applications of biological microscopic images.
1. Microscopic imaging
Digital imaging: 5 megapixel scientific grade CMOS digital camera, true color
Resolution: 1.0 micrometers
2. Microscopic image processing
Image display: Real time dynamic observation, capturing images of any field of view at any time
Image editing: With functions such as cutting, flipping, and annotation text input for any area of the image
Image adjustment: Image brightness, contrast, saturation, RGB channel can be adjusted arbitrarily, with automatic white balance
Image sharpening: By enhancing the high-frequency components of the image, the edges of the image become clearer and sharper
Image smoothing: Through image smoothing processing, the background of the image is evenly smoothed.
3. Micro target measurement
Calibration: With online calibration function for the measurement system, achieving accurate measurement
Measurement annotation: functions such as adding measurement annotations, shifting measurement parameters, and image scaling
Measurement function: Accurate measurement of length, angle, polygon, arbitrary curve and arc, number of points, area, etc
Square measurement: Square measurement measures length, width, perimeter, and area
Circular measurement: Circular measurement of circumference, area, and diameter
Arc measurement: can measure the arc length, angle, and radius of any curve arc
Data output: Export measurement data to Excel or TXT
4. Optical system: DCIS infinitely distant color difference independent correction optical system (or equivalent), with a large and flat field of view, resulting in excellent optical imaging quality.
Observation tube: Hinged binocular, with a tilt of 30 ° and 360 ° rotation, adjustable range of pupil distance: 52-75mm
Eyepiece: High eye point, large field, flat field eyepiece, WF10X/18mm
Objective lenses: Infinite achromatic objective lenses 4X, 10X, 40X (0.65, spring), 100X (1.25 oil lens, spring)
Converter: tilting 4-hole converter
Loading platform: 142 * 135mm double-layer composite mechanical mobile platform, moving range: 76 * 52mm
Spotlight mirror: NA1.25 Abbe spotlight mirror, handwheel lifting type, equipped with phase contrast, dark field slot, and center adjustment device
Focusing mechanism: low coarse moving coaxial focusing handwheel; Micro handwheel 0.1mm/revolution, grid value 0.001mm; The smaller the fine-tuning grid value, the clearer the focus; Adjustable coarse elasticity, 14mm/revolution.
Safety design: upper limit safety device of the workbench, with a maximum stroke of 20mm
Lighting device: 100V-240V switch power supply, 6V20W halogen lamp, continuously adjustable brightness
5. 5 million pixel scientific grade CMOS digital camera optical interface: 1/2.5 inch, C-type imaging interface
Resolution: 2560 * 1944, color depth of 12bit, 5 million pixels
Pixel size: 3
