Technical Features of Children-Wheelchair Technology)
- Safety Protection Design
Full-body Seat Belt System: Three-point or five-point seat belts are used to prevent children from climbing or sliding. The buckles adopt anti-misoperation designs.
Anti-backflip Wheels: Auxiliary wheels are added on both sides of the rear wheels to avoid tipping when going up or down slopes. The height can be adjusted to suit different age groups.
Emergency Braking Device: A dual braking system with hand control and foot pedal is provided. The response time is ≤ 0.5 seconds, and it supports automatic locking on slopes.
- Dimension and Comfort Optimization
Adjustable Seat Parameters:
Seat width: 25 - 32 cm (suitable for the body shapes of children aged 3 - 12 years old), equipped with detachable cushions.
Backrest height: 35 - 45 cm, with built-in lumbar support, supporting an inclination adjustment of 0 - 15°.
Foldable Footrest Design: The height from the ground can be adjusted between 12 - 18 cm, and it can be folded upwards to save space during storage.
- Power and Control System
Low-power Safety Motor: The power of a single motor is 100W (200W in total), and the maximum speed is 3.5 km/h to prevent excessive speed.
Intelligent Control Panel:
The buttons are marked with cartoon patterns (such as animal buttons), and they have a soft touch, which is suitable for children's fingers to press.
It is equipped with a parental remote control function, and the speed can be limited and the direction can be locked through a Bluetooth APP.
- Adaptation to Special Scenarios
Lightweight Track Structure:
The track width is 15 cm, and the material is environmentally friendly rubber. The noise is ≤ 55 dB when climbing stairs to avoid scaring children.
The climbing angle is ≤ 12°, and the height of the stair steps is adapted to standard steps of 15 - 20 cm.
Anti-slip and Shock-absorbing Configuration:
The front wheels use 6-inch PU honeycomb wheels, and the rear wheels are equipped with spring shock absorbers. The vibration amplitude is ≤ 30% when passing through bumpy roads.
- Interaction and Fun Design
Multimedia Integration: A detachable tablet holder is built into the backrest of the seat, which supports playing early education content. The volume is automatically limited to below 70 dB.
Customizable Appearance Elements:
Cartoon color schemes (such as bright yellow, pink) are available, and magnetic cartoon stickers can be attached to the body.
Snack boxes and cup holders are designed on the armrests, with capacities of 300 ml and 200 ml respectively.
