The visual appearance of the product is blent into the simple concept, stylish and generous. Specially makes
the fine pouring cast-aluminum outer covering,so as to enhance the balance of the anti-static anti-jamming capability.The panel with five operational button,Sliding glass windscreen provide big space,Insightful vision and
operate easily.We use high precision magnet sensor to keep the weighing more fast and stable.
* Electromagnetic sensor
* Aluminum shell/Large space Wind proof cover
* LCD (White back light with black font)
* Tare function/Counting/Unit conversion
(g/mg/ct/oz)
* Sensitivity/Speed set
* Overload alarm/Fault alarm/ Level indicator
|
FA Series |
||||||
|
Model |
FA1004 |
FA1104 |
FA1204 |
FA2004 |
FA2104 |
FA2204 |
|
Capacity(g) |
100 |
110 |
120 |
200 |
210 |
220 |
|
Resolution(g) |
0.0001 |
|||||
|
Min weighing(g) |
0.0004 |
|||||
|
Stable Time |
≤3s |
|||||
|
Display |
LCD（white back light with black font） |
|||||
|
Pan size |
Φ80mm |
|||||
|
Operation temp |
5-25℃ |
|||||
|
Repeat ability |
±0.0002g |
|||||
|
Liner |
±0.0003g |
|||||
|
Draft shield size |
240mmx190mmx265mm |
|||||
|
Cal.weight |
100g |
200g |
||||
|
Option |
RS232C & RS486、Printer |
|||||
|
Packing size |
Inside：415x285x430mm Outside：475x315x485mm |
|||||
|
G . weight |
10kg |
|||||
