Introduction:
It is widely used in bacterial culture, fermentation, hybridization, biochemical reaction, enzyme and cell tissue research. It has extensive and major applications in research and application fields such as biology, molecular science, food, and environment.
| Features: *High-quality servo motor. *Multi-steps rotate speed, temperature and time control systems. *Slow accelerate and decelerate design. *Advantaged air duct design. *Automatic defrosting function. *High-precision speed control. *High-precision temperature control. |
*Unique drive system. *Open door protection. *LCD display with bright illumination. *Memorized and protected operating parameters. *Continuously running or timing. *Unique slow-start design. *Standard of illumination and UV light. |
Introduction:
It is widely used in bacterial culture, fermentation, hybridization, biochemical reaction, enzyme and cell tissue research. It has extensive and major applications in research and application fields such as biology, molecular science, food, and environment.
|
Features: *High-quality servo motor. *Multi-steps rotate speed, temperature and time control systems. *Slow accelerate and decelerate design. *Advantaged air duct design. *Automatic defrosting function. *High-precision speed control. *High-precision temperature control. |
*Unique drive system. *Open door protection. *LCD display with bright illumination. *Memorized and protected operating parameters. *Continuously running or timing. *Unique slow-start design. *Standard of illumination and UV light. |
Technical Parameters:
|
Model |
BJPX-2012N BJPX-2012RN |
|
|
Capacity |
180L(Per unit) |
|
|
Temp. sensor |
PT100 |
|
|
Temp. Range |
RT+5~65℃ |
4~65℃@20℃) |
|
Temp. Fluctuation |
≤0.1℃@37℃) |
|
|
Temp. Uniformity |
±0.6℃ (@37℃) |
|
|
Temp. Precision |
±0.1℃ |
|
|
Timing Range |
0~9999h/min or continuous |
|
|
Controller |
PID |
|
|
Display |
LCD |
|
|
Circulation Mode |
Forced convection |
|
|
Shaking Mode |
Rotary shaking |
|
|
Drive Mode |
Multidimensional drive |
|
|
Vibration Range |
φ26mm (Can customize φ35(20~250rpm); φ50(20~200rpm) |
|
|
Rotating Speed |
0;20~350rpm(Top layer 20~300rpm, static culture, reverse rotation or alternate operation) |
|
|
Rotating Accuracy |
±1rpm |
|
|
Shaking Plate Size |
610*460mm |
|
|
Shaking Plate Quantity |
1pc |
|
|
Max.Capacity |
250ml*32 or 500ml*21 or 1000ml*13 or 2000ml*7(Flask clamp) 250ml*32 or 500ml*20 or 1000ml*12 or 2000ml*8(haft Platte) |
|
|
Standard Capacity |
Flask clamp:500ml*20 |
|
|
Internal Material |
Stainless steel |
|
|
External Material |
Sprayed steel plate |
|
|
Refrigerant |
/ R134a |
|
|
Heating Consumption |
800~900W |
|
|
Safety Function |
Audio and visual alarm for over-temperature Alarm for over-speeds Independent over-temperature protector Shutdown protection for door opening Leakage or over-current protection Ultraviolet disinfection function Calibration of monitoring temperature and ambient temperature Overload protection of refrigeration unit and delayed start of incoming call (only BJPX-2012RN) |
|
|
Consumption |
1000W(Per unit) |
1200W(Per unit) |
|
Power Supply |
AC 220V,50Hz(Standard);110V,60Hz(Optional, external transformer) |
|
|
Internal Size(W*D*H) |
715*580*450mm(Per unit) |
|
|
External Size(W*D*H) |
1120*790*620mm(Per unit) |
|
|
Package Size(W*D*H) |
1275*950*810mm(Per unit) |
|
|
Gross Weight |
220kg(Per unit) |
|
