Working Principle
The organic matters in the sample are oxidized by UV lamp and converted into carbon
dioxide. Then TOC analyzer adopts membrane / conductivity detection technology to
measure the concentration of carbon dioxide, inoxidized sample’s TIC and IC and then
report the results. Here TC and TIC are detected and TOC is equal to TC minus TIC
(TOC = TC-TIC).
Features
1. Membrane / conductivity testing technology, oxidant and UV oxidation technology;
2. Automatic alarm when exceed the limit value;
3. It can exclude the interference of haloid and hydrocarbons;
4. Keep the last 12 months’ record automatically, able to look up the record and print the
5. test results;
6. Operation and maintenance are simple, fast, reliable;
7. Calibration method is simple; you can get the calibration liquid from Tailin or prepare it
by yourself.
Applications
It can measure the TOC value contained in pure water, deionization water and WFI;
Pharmaceutical and biological chemical cleaning validation: The instrument can be used
to monitor the water during circulation cleaning in pharmaceutical and biochemical
industry;
Monitor the TOC value contained in the purified water of semiconductors.
Technical Parameters
Power supply: AC 220V/50Hz
Power: 150W
Detection limit: 0.01mg / L
Detection accuracy: ± 5%
Detection range: 0.01mg/L-25.00mg/L
Analysis time: 6min
Response time: within 30min
Sample temperature :1~ 95 ℃
